Single Screw Extrusion Line for Endotracheal and Infusion Tube

This series of equipment consists of single screw extruder, extrusion die, vacuum forming cooling tank, belt haul-off unit and servo cutter, Equipment and product contact surface can be made of stainless steel (SUS316) or custom designed to match customer' s requirements.

This series of equipment consists ofsingle screw extruder, extrusion die, vacuum forming cooling tank, belt haul-off unit and servo cutter, Equipment and product contact surface can be made of stainless steel (SUS316) or custom designed to match customer' s requirements.
Applicable materials: PVC;TPV;TPU and other materials for medical application.
Applicable tubes: Nasal oxygen cannula,tracheal intubation, infusion tube,elastomeric infusion tube, double-cavity, multi-cavity and single row tube, etc.
Applicable tube diameter and margin oftolerance: outside diameter: 1.5-20mm; dimensional tolerance ofoutside diameter: +/-0.01,+/-0.02,+/-0.05mm; wall thickness:0.1-3.0mm.
